RSC-1, Communications Adapter

Part Number: RSC-1
Manufacturer: Morningstar
Length: 2.83 IN
Width: 1.37 IN
Thickness: 0.90 IN
PDF-Datasheet: Download Here

By converting to EIA-485, the RSC-1 allows up to 128 Morningstar products to communicate on the same communication bus and over much greater distances.

Typical configurations include:

  • Networking several TriStar and/or TriStar-MPPT controllers
  • Adding Morningstar’s PC Meterbus Adapters (MSC) for use with an RJ-11 port in multi-device networks.
  • Adding Morningstar’s Relay Driver to a network
  • Integrating any compatible Morningstar product into an existing EIA-485 network, such as those used by industrial control or SCADA systems.
  • All data is transmitted in the form of MODBUS protocol. This industry standard was chosen for its robust design and high level of compatibility with a variety of equipment. Each Morningstar product has its own
  • MODBUS specification (see our website for full details) that covers the data available from each products specific functions.

Key Features and Benefits

  • Removable four (4) position EIA-485 terminal
  • 9-pin RS-232 connector (male)
  • Status LED for monitoring and diagnostics
  • Molded tabs for attachment to 35mm standard DIN rail
  • RS-232 ribbon cable (not shown) with low-profile connectors
